Division Street North Branch Canal Bridge

Division Street Eastern Bridge




Division Street North Branch Canal Bridge

Primary Photographer(s): Nathan Holth

Bridge Documented: August 12, 2006, October 2010, and September 10, 2012
View Photos
and Videos
View Maps
and Links

Key Facts

Facility Carried / Feature Intersected
Division Street Over North Branch Chicago River Canal
Location
Chicago: Cook County, Illinois
Structure Type
Metal Rivet-Connected Pratt Through Truss, Movable: Double Leaf Bascule (Fixed Trunnion) and Approach Spans: Metal Stringer (Multi-Beam), Fixed
Construction Date and Builder / Engineer
1904 By Builder/Contractor: Roemheld and Gallery and Engineer/Design: City of Chicago

Technical Facts

Rehabilitation Date
1992
Main Span Length
173 Feet (52.7 Meters)
Structure Length
260 Feet (79.2 Meters)
Roadway Width
39 Feet (11.9 Meters)
Spans
1 Main Span(s) and 4 Approach Span(s)
NBI Number
16601526637

Historic Significance Rating (HSR)

Bridge Documentation

This Bridge No Longer Exists!

View Archived National Bridge Inventory Report - Has Additional Details and Evaluation

View Historic American Engineering Record (HAER) Documentation For This Bridge

HAER Data Pages, PDF

This extremely significant historic bridge was demolished Summer 2014!

Summer 2014 Demolition Comments

This bridge is one of the most historic bridges in Chicago. With its decorative portals, it is also unique. Despite this the bridge has not been maintained like the historic bridges in downtown Chicago. The bridge has become so deteriorated that the city is now planning to demolish and replace the bridge with a temporary bridge in Summer 2014, until a project to build a new permanent bridge can be realized.

HistoricBridges.org has several concerns with this. First, this project as proposed results in the loss of a highly significant and unique historic bridge in Chicago. This could and should have been avoided. Rather than demolish this historic bridge, the trusses could be carefully lifted off the canal, allowing for the temporary bridge to be put in place. Then, the trusses of this bridge could be shipped off to a shop where they could be carefully rehabilitated, with areas deteriorated beyond repair being  replaced in kind. Then, several things could happen. The trusses could be reinstalled over the river as a rehabilitated permanent bridge for Division Street. Alternatively, a new superstructure could be built over the canal, and the trusses could be placed on top of the replacement bridge as a decorative element. This sort of process can be observed with the Washington Avenue Bridge in Minneapolis. Another option would be to reuse the rehabilitated trusses in a new location, either on a road for vehicular use, or on a trail for pedestrian use. Finally, at the absolute very least these trusses should be salvaged, repainted, and placed in a park setting in the Chicagoland area as a non-functional interpretive exhibit.

Given the significance of this bridge and all the preservation options presented above, the planned demolition of this bridge's beautiful trusses is both highly disappointing and unnecessary. This bridge represents the beginning of Chicago's bascule bridge heritage and it deserves more than to be cut up, shipped to China, melted down, and turned into soup cans!

About This Bridge

Division Avenue North Branch Canal Bridge RaisedArmour Engineer Cover With Bascule BridgeCrossing the North Branch Chicago River Canal onto or off of Goose Island, this is one of the very first highway bascule bridges built in Chicago, constructed just a couple years after Cortland Street. Given the influence that Chicago's development of the bascule bridge had on bridge construction nationwide, this prototypical example of a Chicago type trunnion bascule bridge is nationally significant and its preservation should be given a paramount level of priority.

 Roemheld & Gallery of Chicago were both the designers and builders of the bridge. This bridge is similar to bridges like Cortland Street, but it has one very unusual and distinctive characteristic which sets it aside from these other bridges. The overhead sway/portal bracing for this bridge is composed of simple plate steel with decorative designs on them that includes an upside-down "Y" design with a circle around it that is used in Chicago to refer to the three branches of the Chicago River. The symbol became an officially designated symbol appearing in Chicago's municipal code as the "Municipal Device." Easy to miss unless you are looking for it, the symbol can be found on buildings and structures throughout the city including on a few other bridges. This Division Street Bridge however is the only bridge in the entire city that includes this design in its overhead bracing. The bridge is different from the other early bascule bridges including the bascule bridge in sight of this one also on Division Street, which have a more intricate network of built-up sections of v-laced and latticed steel for bracing. The plates with the Municipal Device symbol on this bridge are an interesting and decorative element that adds a lot to the bridge.

Division Avenue North Branch Canal BridgeSome authors and historians have criticized the earliest bascule bridges including this one as lacking aesthetics. And while indeed, bridges like this may have not been in keeping with the aesthetic desires of the time in which they were built, two things are clear today. First, in today's world of simplistic bridges, bridges such as this do have aesthetic value in the context of the modern world. The complex trusses made up of equally complex components like built-up beams with v-lacing and lattice offer an intricate geometric beauty that is not found in any form of modern bridge. The early bascule bridges of Chicago, like this bridge, have very tall trusses with overhead bracing, and this unavoidable design catches the attention of travelers and lets them know in no uncertain terms that they are crossing a bridge. This characteristic is lost on most modern bridges. In the context of the modern world, these elements have a positive effect on the aesthetic qualities of the road and location they serve. In the case of the Division Street bridge, the decorative designs found on the overhead bracing only add to the aesthetic qualities of the bridge. These designs are remnants of a different era of aesthetics, quite different from the type of aesthetics found on Chicago's bascule bridges that were built in the 1920s and 1930s for example. In the late 1800s, bridges were often metal truss bridges that lacked curved beams and did not have a very graceful design. This did not mean that the bridges were not beautiful or lacked aesthetic qualities, however. In this period, a more heavy reliance was placed on adornments like finials, portal cresting, and decorative builder plaques. Generally aesthetic enhancements to the actual bridge structure was often limited to the use of decorative bracing which might have attractive curved designs, or cutout shapes (like those found on the Division Street Bridge). The purpose of all these enhancements was to accent and decorate the bridges. In contrast, in the 20th Century, the use of concrete in bridge construction gave engineers the ability to create bridges that had graceful arches, with decorative elements cast directly into the concrete as well. Concrete also allowed for more streamlined and simplistic bridge designs. This along with general changes in architectural trends (like Art Deco) led to significant changes in what an "aesthetically pleasing" bridge was thought to be. This focus on streamlining, curves, and a generally graceful appearance is also evident in the later examples of Chicago bascule bridge.  The Division Street Bridge thus appears at the end of one era of architecture and before the new era had really managed to take hold in Chicago.

The previous bridge at this location was also the first documented bridge at this location. It was built in 1870 and was a hand-turned iron/wood combination bridge built by Fox and Howard. It was 176 feet long and 29 feet wide.

Division Avenue North Branch Canal BridgeF. W. Blocki

Division Avenue North Branch Canal Bridge
