This bridge is an unaltered, still functioning, and excellent example of a traditional Chicago bascule bridge on the Calumet River. Its trusses follow a similar design to some of the other bascule bridges on the Calumet River as well as on the Sanitary and Ship Canal. The bridge retains its original, handsomely decorated bridgetender buildings and the historic integrity of the trusses is good as well. It would appear that the original pedestrian railings have been replaced however.
The Ketler-Elliott Company constructed the superstructure, while the Fitzsimons and Connell Company constructed the substructure. A photo of founder Charles Fitz Simons is shown below.
Thanks to Tom Winkle for providing boat transportation to assist in the photo-documentation of this historic bridge.
Truss bridges with riveted connections like the 100th Street Bridge required riveting in the field where the members of the truss were riveted together at the connection gusset plates. In the field, rivets would be heated in a portable forge. One of the most common types is shown to the left, with a diagram of the blower for this forge shown to the right. Larger forges were also used to efficiently heat larger quantities of rivets, and these were called rivet furnaces. A few examples from the early 20th Century are shown below.
|
Main Plaque WM HALE THOMPSONMAYOR
CHICAGO PLAN COMMISSION BENNETT PARSONS & FROST - CONSULTING ARCHITECTS CHICAGO CHAPTER OF AMERICAN INSTITUTE OF ARCHITECTS ILLINOIS SOCIETY OF ARCHITECTS CHICAGO ART COMMISSION
JAMES J. BARRETT - PLUMBING 1927 |
